Commercial RO System

OUR WATER PROFESSIONALS WILL HELP YOU BUILD YOUR OWN HIGH VOLUME COMMERCIAL RO SYSTEM
Home ·Our Services ·Commercial RO System

COMMERCIAL REVERSE OSMOSIS SYSTEMS; FROM IRRIGATION TO CAR WASHES

We have all sizes of commercial RO systems, if you need help sizing a commercial water system call our customer service staff, +971 523393683, and we'll build that perfect commercial reverse osmosis water system for your business.

Coffee shops, marijuana, hemp and cannabis farms, hydroponics, restaurants, food service, breweries, hotels, motels, farms, ranches, car washes, window cleaning companies, aquariums, and solar panel cleaners all rely on high volume, commercial reverse osmosis systems to filter their water. Any of our commercial or industrial sized reverse osmosis water filtering systems can deliver that high volume clean water. If your business uses clean, pure, filtered water, our systems can deliver. Get the cleanest water possible and filter out harmful contaminants from your water.

  • A high-volume, commercial water filtering system can be adjusted to satisfy the chemistry of your water used by any given business.
  • Typically, geography determines exactly what contaminants exist in your water supply.
  • We make sure that each system targets whatever contaminants remain in the water through a water analysis test.
  • This way we can ensure we're removing the right contaminants and leaving your water crystal clear for your business.

The Process of Reverse Osmosis

Osmosis is a natural process. When two liquids with differing concentrations of a solute are separated by a semi-permeable membrane, the liquid tends to move from low to high solute concentrations to reach equilibrium.

Reverse osmosis is a process whereby a solvent of high solute concentration is forced through a semi-permeable membrane to an area of low solute concentration by applying pressure. The feed water pressure must exceed the osmotic pressure in order for the process to work. Thus, low pressure systems work with more dilute solutions, but highly concentrated solutions (such as sea water desalination) require greater pressures to work. The fact of the matter is that reverse osmosis is the most economical technology to purify water to extremely high quality standards.

Application
Designing
Solution

What Makes Up a Complete Reverse Osmosis System? A typical reverse osmosis system is much more than just to RO Component. A complete Reverse Osmosis System generally includes several other components, such as:

Pre-Treatment this includes carbon filters to remove chlorine, iron, manganese and sulfur filters, water softeners or ant-scalant systems.

Post-Treatment this includes ultraviolet disinfection (UV) or ozonation to kill bacteria, pH adjustment to raise the pH or add some hardness back to the water and/or deionization to totally demineralize the water.

Instrumentation " monitoring the end water quality is often desirable, so a number of instruments and analyzers are available to facilitate that.

Storage and Distribution RO systems make water slowly, so a tank is required. There are two (2) types of tanks " atmospheric and bladder types. Atmospheric types are typically bigger and since there is no bladder to supply back-pressure, the water quality is higher in an atmospheric tank verses a bladder tank. Smaller systems (generally under 1, 000 gpd often use bladder tanks from 14 to 80 gallons, while larger volume systems use atmospheric tanks from 75 gallons to 2, 000 gallons. When using an atmospheric tank a booster pump must be utilized to re-pressure the water and distribute it.

Designing a Commercial-Industrial Reverse Osmosis System

A commercial RO functions at its highest level when it is fed into an open-air or atmospheric tank. With no back-pressure from the bladder of a pressurized storage tank, a commercial RO will deliver water that is extremely low in TDS; it's not unusual for the TDS to be near ZERO when the RO is discharged into a atmospheric pressure tank. In food service applications or other applications where extremely low or ZERO TDS is not critical, a bladder tank can be utilized, but if a manufacturing process calls for extremely low TDS water, then the atmospheric tank is far and away the best solution.

Proper pre-treatment is necessary for successful and economical operation of a commercial RO system. The water needs to be as soft as possible or a scalant needs to be fed ahead of the system to prevent membrane scaling. In most cases, a water softener and backwashing carbon filter are the preferred and most cost effective method of pretreatment.

An atmospheric tank is required for storage of the RO water, and US Water offers atmospheric tanks in sizes from 20 gallons to 9, 000 gallons, as well as every size in between. Additionally, the water needs to be re-pressurized out of the atmospheric tank(s) so several pumps of high purity water are offered as well as ultraviolet disinfection, UV, which kills any airborne or waterborne bacteria which could intrude into the atmospheric tank.

Additionally, US Water offers Deionization, DI, of the water for ultrapure applications, such as laboratory water and semi-conductor manufacturing, as well as instrumentation and monitoring.

Membrane Solution We provide membrane solutions for any type of water, however, the reverse osmosis system is only part of the solution. US Water offer the complete solution to all of your water problems, including:

Pre-Treatment Solutions - Filtration, oxidation, softening, anti-scalants and disinfection

Post-Treatment Options - Ozonation, ultraviolet, pH adjustment, deionization and carbon filtration

Storage Solutions - Atmospheric tanks or bladder tanks with liquid level controls

Distribution Systems - Pumps, including variable speed pumps

Components - Membranes, housings, motors, controls and repair parts
